Waco Gigant

WACO moulder, type Gigant

Machine specifications:

- Planing width max. 250 mm

- Planing height max. 100 mm

- Hydraulic feeding system, motor 30 kW

- Feed speed max. 120 m/min

Spindle lay-out:

1. Horizontal spindle bottom, motor 18.5 kW

2. Horizontal spindle top, motor 18.5 kW

3. Vertical spindle right, motor 15 kW

4. Vertical spindle left, motor 18.5 kW

5. Vertical spindle right, motor 15 kW

6. Vertical spindle left, motor 18.5 kW

7. Horizontal spindle top, motor 18.5 kW

8. Horizontal spindle bottom, motor 11 kW

9. Horizontal spindle bottom, motor 18.5 kW

- 4 pc. heavy duty feeding units

- Pneumatic top and side pressures

- Separate electricity trunk with control panel

- Incl. accessories
